Australia Standard Structural Plywood

Short Description:



  • Structural Plywood is typically a high-quality product coming in 4′ x 8′ two-sided marine grade panels in thicknesses ranging from ⅛” to 1″.
  • Supply Ability: 5000CBM/Month
  • Payment Terms:  T/T or L/C
  • Delivery Time: Within 20 days after deposit confirmation
  • Certification: CE, FSC, EUTR, CARB,EPA, JAS, ISO
  • Material:   Radiata Pine, Russia Larch
  • Size: 1200×2400/1200x1800MM
  • Thickness: 4MM–30MM/custom
  • Glue:  Phenolic-WBP/Custom
  • Formaldehyde Release: E0≤0.5mg/L, E1≤1.5mg/L, E2≤5.0mg/L
  • Density: 560-700KGS/CBM
  • Moisture Content:  <12%




Product Detail

Structural Plywood has been manufactured at our plant in China, for in excess of 15 years and has been used successfully in Asia, Australia, and New Zealand.

Structual plywood for strong, stable. Structural Plywood has been manufactured at our plant in China, for in excess of 15 years and has been used successfully in Asia, Australia, and New Zealand.
For domestic and light commercial structural and decorative applications manufactures structural plywood in a range of widths, lengths, thicknesses, and grades to AS/NZS2269 from Newzealand and Russia-sourced plantation Radiata Pine and Larch. Products are certified by Certmark.
Structural plywood is for use in all permanent structural and engineered applications.
A Bond is durable and permanent under conditions of full weather exposure and long-term stress.
Structural plywood should be preservative-treated to ensure it lasts its full-service life as it is manufactured from a range of hardwood and softwood timber species.
For termite and rot resistance, plywood can be treated to H2, H3, or H4 standards. Or for a lower-cost alternative can be manufactured with a bifenthrin glue line additive which provides termite resistance but is only suitable for use south of the tropic of Capricorn.
Testing and certification are carried out by Certemark International (CMI) and DNV.
Formply provides assurance of quality and consistency.

Introduction

Australia Standard Structural Plywood is a type of plywood that is manufactured to meet Australian standards for structural applications. This means that it has been tested and certified to meet specific performance requirements for use in load-bearing applications in the construction industry.

The plywood is typically made from high-quality plantation-grown hardwood species such as eucalyptus or pine. It is made by bonding together multiple layers of thin wood veneers with an adhesive, with each layer’s grain running perpendicular to the previous layer. This construction provides strength and stability to the plywood, making it suitable for use in load-bearing applications such as walls, floors, and roofs.

Australia Standard Structural Plywood is available in a range of thicknesses, typically from 7mm to 25mm, and in standard sheet sizes of 2400mm x 1200mm or 2700mm x 1200mm. It is manufactured to meet strict Australian standards, including the AS/NZS 2269 Plywood Structural standard, which sets out requirements for strength, durability, and workmanship.

Australia Standard Structural Plywood Feature

1. Strength: Australia Standard Structural Plywood is designed to be strong and durable, making it suitable for use in load-bearing applications in the construction industry. It is made from high-quality hardwood species and is constructed with each layer’s grain running perpendicular to the previous layer, providing strength and stability.
2. Durability: Australia Standard Structural Plywood is manufactured to meet strict Australian standards for strength, durability, and workmanship. It is designed to withstand harsh weather conditions and is resistant to moisture, rot, and pests.
3. Versatility: Australia Standard Structural Plywood is a versatile building material that can be used in a wide range of applications, including walls, floors, roofs, and structural framing. It is available in various thicknesses and sizes, making it suitable for both small and large construction projects.
4. Sustainability: Australia Standard Structural Plywood is made from high-quality plantation-grown hardwood species, which are renewable resources. The plywood manufacturing process also uses advanced technologies and techniques to minimize waste and reduce environmental impact.
5. Compliance with Australian Standards: Australia Standard Structural Plywood is manufactured to meet strict Australian standards, including the AS/NZS 2269 Plywood Structural standard, which sets out requirements for strength, durability, and workmanship. This means that builders and contractors can trust that the plywood will meet the necessary performance requirements for load-bearing applications in the construction industry.

Normal Thickness Sheet Size (mm) Grade Density   (kg/cm) Face and back Core Materials Moisture Glue Thickness Tolerance Packing Unit ( sheets )
1/8inch  (2.7-4.0mm) 1200×2400 A/B 580 Larch/ Pine Larch/hardwood/ pine 8-14 % Waterproof Super E0 +/-0.2mm 150 / 400
1/2inch (12-12.7mm) 1200×2400 B/C 550 Larch/ Pine Larch/hardwood/ pine 8-14 % +/-0.5mm 70 / 90
5/8inch (15-16mm) 1200×2400 C/C 530 Larch/ Pine Larch/hardwood/ pine 8-14 % +/-0.5mm 60 / 70
3/4inch (18-19mm) 1200×2400 C/D 520 Larch/ Pine Larch/hardwood/ pine 8-14 % +/-0.5mm 50 / 60
structure plywood 03

Advantages of HW Structural Plywood

Manufactured from sustainably-grown plantation pine and Larch
Available in B, C, and D surface appearance grades
Sheet thicknesses: 3 to 40mm
Sheet dimensions: 2400/1800 × 1200mm
Supplied in F8/F27 stress grade
Uncoated high-appearance surface suitable for clear, stain, and paint finishes
Contains a second void-free layer under the surface veneer increasing protection
from moisture bubbles and high-point loads
Low formaldehyde emission (E0)

usage 01
usage 02
pr2
pr3

Application of HW Structural Plywood

usage 03
usage 04
ASF Horner LS PR2 North Maple

Packaging and Containerization of HW Structural Plywood

6
IMG_20210309_151401_副本
1
IMG_20201219_145022_副本
2
packing 03

FAQ

Q: What is the difference between structural and non-structural plywood?

A: Structural plywood is designed and manufactured to meet specific performance requirements for load-bearing applications in the construction industry, while non-structural plywood is designed for use in non-load-bearing applications such as wall paneling, furniture, and decorative purposes.

Q: What are the applications of Australia Standard Structural Plywood?

A: Australia Standard Structural Plywood can be used in a wide range of load-bearing applications in the construction industry, including walls, floors, roofs, and structural framing.

Q: What sizes are available for Australia Standard Structural Plywood?

A: Australia Standard Structural Plywood is typically available in thicknesses ranging from 7mm to 25mm and in standard sheet sizes of 2400mm x 1200mm or 2700mm x 1200mm. Other sizes may be available upon request.

Q: How is Australia’s Standard Structural Plywood manufactured?

A: Australia Standard Structural Plywood is manufactured by bonding together multiple layers of thin wood veneers with an adhesive, with each layer’s grain running perpendicular to the previous layer. This construction provides strength and stability to the plywood.

Q: Is Australia Standard Structural Plywood environmentally friendly?

A: Australia Standard Structural Plywood is made from high-quality plantation-grown hardwood species, which are a renewable resource. The plywood manufacturing process also uses advanced technologies and techniques to minimize waste and reduce environmental impact.
